Hager AB7507 - AB7509, Concealed Anti-Friction Bearing, Steel, Heavy Weight, 3 Knuckle, Anchor Hinge with 2 Anchor Leaves

Full Mortise architectural anchor hinge with two anchor leaves and three knuckles, by Hager Companies. Hinge is concealed anti-friction bearing and heavy weight for use on heavy weight doors receiving high frequency service and using concealed door closer. Size of hinge is 5" x 4-1/2" and there are a variety of finishes available.

PRICED PER PIECE - See full product details and specs in the tabs below

See Hager Hinges Color Chart for a detailed list of Hager finishes.

See tabs below for additional information
    • SKU
      HGAB7507-5x4.5-LH-US26D
    • Market price:$422.85
      • save 50%
    • Starting price: Price: $211.43 per item


     This commercial grade Architectural hinge, by Hager Companies, is a full mortise anchor hinge with one anchor leaf screwed to the frame and one to the top of the door. It is a three knuckle, concealed anti-friction bearing hinge and heavy weight.  HAB7507 is for square edge doors. HAB7509 is for beveled edge doors.

    Must be used with one pair heavy weight, full mortise hinges (AB750 or AB850)-sold separately.

    Hinge Size: 5" x 4-1/2"

    Hinge SizeGauge of Metal
    Hole
    Count
    Screw Size
      Inches  mm      Machine  Wood
      5" x 4-1/2"   127 x 114   0.190   15 1/2 x 12-24  1-1/4 x 12

    Hinge is provided with a non-removable pin (NRP). Pins which have a groove milled into them. A set screw is inserted through the middle knuckle into the groove. This way the pin, hinge and door cannot be removed by burglars and the like. Flush pin and plug.

    • Option of Non-removable pin (NRP). Pins which have a groove milled into them. A set screw is inserted through the middle knuckle into the groove. This way the pin, hinge and door cannot be removed by burglars and the like.
    • Handed: This hinge is available for right handed or left handed doors, specify when ordering. Click here to learn How to Determine Handing.
    • Custom colors available. For details and pricing please contact us or call us at 845-388-1300.

    Priced per piece.

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product data tab for exact measurements.

    This product has a lifetime guarantee against defects in workmanship and materials.

    Click here to view a Steel Hager Hinge.

    To view all hinges in this category, see How to Choose a 3 Knuckle Anchor Hinge.

      • SKU
        HGAB7507-5x4.5-LH-US26D
    • QuickShip
      No
    • Manufacturer
      Hager Companies
    • MPN
      AB7507/AB7509
    • Handing
      Left Handed, Right Handed
    • Door Edge Type
      Square Edge Doors, Beveled Edge Doors
    • Product Design
      • Hinge Category
        Full Mortised Hinge, Anchor Hinge
      • Base Material
        Steel
      • Usage Level
        Heavy Duty
      • Throw
        Standard Throw
      • Bearing Type
        Concealed Anti-Friction
      • Knuckles
        3 Knuckle Hinge
      • Pin Type
        Standard Hinge Pin
      • Hinge Tip Type
        Button Tip
      • Hinge Corner
        Square Corner
      • Hole Pattern
        Commercial "C" Pattern
      • Number of Holes
        15 Holes
    • Dimensions
      • Hinge Size
        5" x 4-1/2"
      • Hinge Thickness
        .190" Thick
    • Installation
      • Installation Screws
        Installation screws provided.

    • Finishes
      • Finish
        Prime Coat (USP), Satin Bronze (US10), Oil Rubbed Bronze (US10B), Satin Chrome (US26D), Antique Bronze (US10A)
    • Compliance Details
      • Compliance Details
        BHMA Certified
      • ANSI Designation
        A8511, A156.18
      • Warranty
        Lifetime Limited Warranty

    Click to Print AB7507 Template-Square Edge Doors

    Click to Print AB7509 Template-Beveled Edge Doors



    Square Edge Door Template. See above for beveled edge door template.



    Hinge complies with ANSI A8511.
