Pemko #R2.25F Modular Ramp, Aluminum 2.25" Height, 28" Length
Modular Ramps are designed to transition offset floor conditions and ease movement for those with limited mobility. This ramp ensures smooth transition for an offset of 2.25". Available in high quality Aluminum or Aluminum PemKote™ Non-Slip surface and optional, though recommended, Miter Returns (see below).
PRICED PER FOOT
Modular Ramps are designed to transition offset floor conditions and ease movement for those with limited mobility. It is made of five components, which interlock to form one sturdy ramp. No welding is required for installation. This ramp is wheelchair compatible and meets the slope requirements for Americans with Disabilities Act (ADA). The grooved surface allows for a stronger grip, to prevent slipping.
Available Finishes: Available in standard Aluminum Mill Finish or with Aluminum PemKote™ Non-Slip Surface. PemKote™ is highly recommended for ramps placed in exterior conditions where moisture may be present.
Miter Return Ends Pieces: The use of Miter Returns are recommended to seal the sides of the ramps. However, the miter returns do not meet the ADA slope requirements and are not ADA compliant. If miter returns are not used, it is recommended to fill and feather the threshold ends with grout - do not leave the ramp ends open.
Widths Available: Standard widths are available for purchase through our website, however, up to 185" can be purchased through our office. For details and pricing, please contact us or call us at 845-388-1300.
Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product specs for exact measurements.
Standard Aluminum product is guaranteed for 5 years against defects in material and workmanship.
PemKote™ finish carries a 10 year guarantee.
Click here to view a higher 2.5" Offset Modular Ramp.
-
QuickShipNo
-
ManufacturerPemko Manufacturing
-
MPNR2.25F, R2.25FMR
- Dimensions
-
Offset Height2.25" Height
-
Width28" Width
-
LengthCustom Cut to Size
-
- Ramp Design
-
MaterialAluminum
-
Ramp ComponentRamp End
-
Ramp TypeFlush Application
-
InstallationSupplied with #10 Stainless Steel wood screws. Expansion shields can be purchased by contacting our office. This ramp has 5 screws per foot. (Ex: a 36" width ramp will have 3 rows of 5 screws, with a total of 15 screws).
-
DrillingDrill holes are provided
-
- Additional Options
-
Miter ReturnNone Required, Aluminum Miter Return (#R2.25FMRA), PemKote™ Miter Return (#R2.25FMRAK)
-
- Finishes
-
FinishMill Finish Aluminum (US27), Aluminum PemKote™
-
- Compliance Details
-
Compliance DetailsFire Rated, ADA Compliant, BHMA Certified
-
Warranty5 Year Limited Warranty, PemKote™ Finish Carries a 10 Year Guarantee
-
