Adams Rite Exit Device EX80, Dummy Pushbar, For Aluminum, Hollow Metal and Wood Doors

Adams Rite Exit Device EX80, Dummy Pushbar, For Aluminum, Hollow Metal and Wood Doors
Adams Rite

This model is an exit device with a dummy pushbar for narrow stile aluminum, hollow metal and wood doors. The product is designed for applications that do not require a latching / locking life-safety exit device. The pushbar may be used in conjunction with a maglock, where the pushbar turns off the magnet and allows exit from the building. Available in a choice of lengths and finishes, choose from the dropdowns below.

See full product details in the tabs below.

PRICED PER PIECE

See tabs below for additional information
    • SKU
      AREX80-313
    • Market price:$549.00
      • save 30%
    • Starting price: Price: $384.30 per item


    Adams Rite exit devices offer accessibility that other access control solutions can't match, with a variety of options to suit any application. This exit device with a dummy pushbar is for narrow stile aluminum, hollow metal and wood doors in non fire-rated applications.

    Click here to print the Adams Rite Exit Device Catalog.

    The product is an exit only device, no entry from outside. Additional trims can be added separately.

    Exit Device LengthStandard Door Opening WidthActive Pushbar Length (as measured with end caps)Back Bar Length
    Regular (R)30" – 36" [762 mm – 914.4 mm]24" [609.6 mm]32-1/8" [816 mm]
    Mid-length (M)30" – 42" [762 mm – 1,066.8 mm]24" [609.6 mm]38-1/8" [968.4 mm]
    Long (L)42" – 48" [1,066.8 mm – 1,219.2 mm]30" [762 mm]44-1/8" [1120.8 mm]

    Device may be field cut to fit opening width between standard lengths by cutting the back bar and filler plate.

    Stile Width: 2" minimum. Fits narrow, medium and wide stile doors.

    Monitoring:

    • The pushbar comes standard with two monitoring switches and is field selectable for active or inactive configuration.
    • Dual switches allow for redundancy where required by code or the operation of a signal device.
    • Monitoring switches may be wired normally open or normally closed to operate maglock, alarm or similar.

    Features:

    • Modern, contoured design with matching metal end caps.
    • Device is easily cut to length in field; mounting end cap has 1/4” overlap for cut coverage.
    • No visible hardware from back once installed.
    • Tested to over 1,000,000 cycles to ensure durability in high-use applications.

    Noise Reduction: Reduces sound and provides smoother operation

    • Impact bumpers - reduce noise from the initial device activation
    • Return control - dampen the sound and control the device returning to its resting state
    • Horizontal and vertical guides - decrease the scraping sound of the active pushbar on the static back bar

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail.

    This product has a 10 year warranty against defects in materials and workmanship.
    Click here to view our Full Warranty Policy.

    Click here to view our Adams Rite Exit Device EX76, Concealed Vertical Rod, For Aluminum and Hollow Metal Doors.

      • SKU
        AREX80-313
    • QuickShip
      No
    • Manufacturer
      Adams Rite
    • MPN
      EX80
    • Product Details
      • Included Parts
        Pushbar, Mounting Hardware Kit, Mounting End Caps Kit, Strain Relief Kit, Inactive Blocking Bracket Kit
      • Exit Device Type
        Dummy
      • Material
        Extruded Aluminum
      • Noise Reduction
        Yes
    • Door Compatibility
      • Door Type
        Single Door, Paired Doors, Narrow Door
      • Door Material
        Aluminum, Hollow Metal, Wood
      • Door Width
        36" Opening Width, 42" Opening Width, 48" Opening Width
      • Door Thickness
        Compatible with all door thicknesses
      • Stile Width
        2" minimum width
    • Dimensions
      • Projection
        2-1/2" Projection
      • Projection when Dogged
        1-3/4" Projection
    • Installation
      • Handing
        Non Handed
    • Finishes
      • Finish
        Dark Bronze Anodized Aluminum (313), Black Anodized (335), Clear Anodized Aluminum (US28)
    • Compliance Details
      • Compliance Details
        UL Listed, ADA Compliant
      • Warranty
        10 Year Limited Warranty

    UL 294 Access Control System Units, Sixth Edition

    NFPA 101 Life Safety Code

    All Adams Rite exit devices fully meet building codes and ADA guidelines for accessibility and clearance.

    Rating

    Custom options are available, please contact us for details and pricing.

    • Alarm option with battery operated or hard-wired power source
