Falcon MA18 Double Dummy Trim, Grade 1

Falcon MA Series Parts
Falcon

For a wide range of commercial applications where locking or latching is not necessary, Falcon MA18 Single Dummy Trim is the best option. Dummy trim for both side of door. Used for door pull or as matching inactive trim.

Lever style See Product Specs tab for more information.

PRICED PER SET-See full product details and specs in the tabs below

See tabs below for additional information
    • SKU
      FLMA18-AG-626
    • Market price:$451.00
      • save 35%
    • Starting price: Price: $293.15 per item


    Click here to view the Falcon MA Series from the Falcon Full Line Catalog

    For a wide range of commercial applications where locking or latching is not necessary, Falcon MA18 Single Dummy Trim is the best option. Dummy trim for both side of door. Used for door pull or as matching inactive trim.

    Extra Heavy Duty, Commercial, Grade 1

    Lever Style: 8 Styles available in Gala trim style or in Napa trim style. Choose from options above.

    Finishes: See options above, See Falcon Finish Chart for a detailed list of Falcon's finishes.

    Split Finishes: Lock can be purchased with one finish for the outside section of the lock and another for the inside. (Available through our office.)

    Trim:

    • Bind resistant trim: Heavy-duty through-bolted inserts clamp the trim on the door assuring proper alignment. Provided with 8-32 screws for strength and thread sealant to prevent loosening.
    • All trim is cast, forged, or wrought and through bolted with thread patch coated screws. Lever trim to have individual heavy duty springs for lever return, and independent rotation in both directions. Return to door style levers meets the 1/2" California State Fire Marshall requirement.

    Door Thickness: 1-3/4" - 1-7/8". Other door thicknesses available through our office.

    Backset: 2-3/4"

    Case: Cold formed steel, zinc dichromate plated, .090” thick.

    Hubs: Hardened steel

    Faceplates: (armored front) 1-1/4" x 8" brass or stainless steel adjustable for door bevel. Reinforced by heavy gauge steel with stabilizing ribs.

    Functions:

    Options available through our office only:

    • Lead Wrapping Case
    • Abrasive Lever Coating
    • Knurled levers
    • Blocking ring and cylinder guards
    • Dust Boxes

    Priced Per Set.

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. Template is not drawn to scale. Accurately scaled template will be supplied with your order.

    Product has a 1-year warranty against defects in material and workmanship
     Click to view our Full Warranty Policy.

    Click here to view our Full Line of Knobs, Levers, and Handlesets

      • SKU
        FLMA18-AG-626
    • QuickShip
      No
    • Manufacturer
      Falcon
    • MPN
      MA18
    • Lever Style
      Avalon-Gala (Rose-AG), Boardwalk-Gala (Rose-BOG), Broadway-Gala (Rose-BRG), Sutro-Gala (Rose-SG), Dane-Gala (Rose-DG), Latitude-Gala (Rose-LTG), Longitude-Gala (Rose-LGG), Quantum-Gala (Rose-QG), Avalon-Napa (Escutcheon-AN), Broadway-Napa (Escutcheon-BRN), Sutro-Napa (Escutcheon-SN), Boardwalk-Napa (Escutcheon-BON), Dane-Napa (Escutcheon-DN), Latitude-Napa (Escutcheon-LTN), Longitude-Napa (Escutcheon-LGN), Quantum-Napa (Escutcheon-QN)
    • Finishes
      • Finish
        Polished Brass (US3), Satin Brass (US4), Oil Rubbed Bronze (US10B), Satin Nickel (US15), Matte Black, Polished Chrome (US26), Satin Chrome (US26D), Satin Stainless Steel (US32D), Aged Bronze (US11E)


    Finishes Comply with the following ANSI/BHMA Codes:

    • Bright Brass - US3/605
    • Satin Brass - US4/606
    • Oil Rubbed Bronze - US10B/613
    • Aged Bronze - US11/643E
    • Satin Nickel - US15/619
    • Matte Black - US19/622
    • Bright Chrome - US26/625
    • Satin Chrome - US26D/626
    • Satin Stainless - US32D/630

    Functions comply with the following ANSI codes:

    • Passage (Non-Keyed) / F01
    • Exit / Connecting (Non-Keyed) / F31
    • Privacy (Non-Keyed) / F02
    • Privacy with inside lever release (Non-Keyed) / F19
    • Privacy with no entry lockout (Non-Keyed) / F22
    • Entry / Office / F21
    • Entry / Office with buttom lockout / F04
    • Holdback / F06
    • Classroom Lock / F84
    • Dormitory Exit / F90
    • Storeroom Lock / F86
    • Apartment Corridor /F12
    • Front Door/ F08
    • Hotel / F15
    • Store Door / F14
    • Apartment Exit / F09
    • Asylum / F30
    • Classroom Security with deadbolt / F34
    • Classroom Security / F32

    *Provide mortise locksets that comply with ANSI A156.13, Series 1000, Operational Grade 1 and Security Grade 1 with all standard trims and conventional mortise cylinders.

    *Locksets comply with UL10B - neutral pressure and UL10C/UBC 7-2 –positive pressure testing requirements.

    *All locks shall be UL listed for 3 hour fire door.
