Hafele EKU Frontino 20 H Forslide Coplanar Door System, For Base Cabinets, Max 44 Lb Door

Hafele EKU Frontino 20 H Forslide Coplanar Door System, For Base Cabinets, Max 44 Lb Door
Hafele

Hafele Frontino 20 H Forslide Hardware System is designed for by-pass base cabinet doors. Coplanar doors slide smoothly with a soft closing mechanism, and sit flush when in a closed position. This product features a three way door adjustment and pre-mounted running system which allows for minimal installation time. Full set included, no additional parts necessary. Can accommodate doors up to 44 LB, with a height up to 39-3/8".

PRICED PER SET

See tabs below for additional information
    • SKU
      HF406.02.060
    • Market price:$2,495.43
      • save 20%
    • Starting price: Price: $1,996.34 per set
    Additional discounts will be applied when added to cart!


    Hafele Frontino 20 H Forslide Hardware System is designed for by-pass base cabinet doors. Full set included.

    Click here to view the Hafele Frontino 20 H Forslide Catalog.

    Application: For base cabinet doors

    Door Dimensions:

    • Max Door Weight: 44 lbs. (20 kg)
    • Max Door Height: 39- 3/8" (1000 mm)
    • Door Thickness: Between 3/4" and 1" (19 and 25 mm)

    Internal Cabinet Width: Choose from the dropdown above.

    Features:

    • Three-way door adjustment
    • Pre-mounted running system allows for minimal installation time
    • Integrated soft opening and soft closing to prevent door slamming
    • Doors slide smoothly and sits flush when in a closed position

    Supplied With:

    • Running gears
    • Guides
    • Stopper
    • Soft closing mechanism
    • Running and guide track

    Full set included, no additional parts necessary.

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product specs for exact measurements.

    This product has a 1 year guarantee against defects in material and workmanship.
     Click here to view our Full Warranty Policy.

    Click here to view Hafele EKU Frontino 20 H OL Forslide, For Upper Cabinets

      • SKU
        HF406.02.060
    • QuickShip
      No
    • Manufacturer
      Hafele
    • MPN
      406.02.060, 406.02.061, 406.02.063, 406.02.064, 406.02.065, 406.02.066
    • Internal Cabinet Width
      47-1/4"- 55-1/16" (1200-1399 mm), 55-1/8" - 62-15/16" (1400-1599 mm), 63" - 70-13/16" (1600-1799 mm), 70-7/8" - 78-11/16" (1800-1999 mm), 78-3/4" - 86-9/16" (2000-2199 mm), 86-5/8" - 94-1/2" (2200-2400)
