Hafele EKU Libra 20 H Set For Vertical Wooden Sliding Doors

Hafele EKU Libra 20 H Set For Vertical Wooden Sliding Doors
Hafele

Hafele EKU Libra 20 H Set, for Vertical Wooden Sliding Doors that weigh up to 44 lbs. For inlay or overlay doors.

See full product details and specs in tabs below

PRICED PER SET

See tabs below for additional information
    • SKU
      HF403.20.001
    • Market price:$1,079.18
      • save 20%
    • Starting price: Price: $863.34 per set


    Sliding Door Hardware:

    Click to view the Eku Libra 20 H Catalog.

    Application:

    • Independent vertical sliding door system for wood doors
    • For inlay or overlay doors

    Minimum Door Thickness: 5/8" (16 mm)

    Minimum Side Panel Thickness: 5/8" (16 mm)

    Maximum Door Width: 63" (1,600 mm)

    Maximum Door Height: 39 3/8" (1,000 mm)

    Door Weight: Up to 44 lbs. (20 kg) Per Door (Weight of door + Weight of sliding door hardware (=.11 lb or 0.050 kg) + Weight of door handle = Total weight of the door)

    Supplied with:

    • 4 Running Gears (two with spring and two with eccentric adjustment)
    • 4 Deflection Rollers (two front and two rear)
    • 2 Door Brackets
    • 2 Cord Brackets
    • 2 Locking Pins for Cord Bracket
    • 2 Cables
    • 4 Cord Cover Plates
    • 2 Guide Brackets for Counterweight
    • 2 Cord Guide Bracket for Counterweight
    • 4 Door Stoppers
    • 4 Clips for Cover Profiles
    • Installation Instructions

    Order Reference: The following products are required. Please order separately.

    Priced Per Set

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail.

    This product has a 1 year guarantee against defects in material and workmanship.
     Click here to view our Full Warranty Policy.

    Click here to view Hafele EKU Regal A 25 H Forslide Set For One Wooden Sliding Door.

      • SKU
        HF403.20.001
    • QuickShip
      No
    • Manufacturer
      Hafele
    • MPN
      403.20.001
