Hager BB1277, Ball Bearing Steel Slip-in Hinge for Aluminum Entrance, Both Leaves Tapped
Hager BB1277 Full Mortised Aluminum Entrance, ball bearing hinge with five knuckles and both leaves tapped. It is made of steel and comes with a non-rising removable steel pin with button tip and plug. Hager BB1277 is a handed hinge. Available in two sizes in the Satin Chrome Finish.
PRICED PER PIECE - See full product details and specs in the tabs below.
Hager BB1277 Full Mortised Aluminum Entrance, ball bearing hinge with five knuckles and both leaves tapped. It is made of steel and comes with a non-rising removable steel pin with button tip and plug. Hager BB1277 is a handed hinge.
Available sizes:
Hinge Size | Gauge of Metal | Hole Count | Screw Size | ||
---|---|---|---|---|---|
Inches | mm | Machine | Wood | ||
4-1/2" x 4" | 114 x 102 | 0.134 | 8 | 1/2 x 12-24 | 1-1/4 x 12 |
4-1/2" x 4-1/2" | 114 x 114 | 0.134 | 8 | 1/2 x 12-24 | 1-1/4 x 12 |
Hinge is provided with a non-rising removable pin with a button tip and plug.
Custom finishes: Available through our office, for details and pricing please contact us or call us at 845-388-1300.
Handing: Left handed and right handed. Click on the link of How to Determine the Handing of a Door
Priced per piece.
Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See Product Specs Tab for exact measurements.
This product has a lifetime guarantee against defects in workmanship and materials.
Click here to view our Full Warranty Policy.
For Plain Bearing Aluminum Entrance Hinges, see our here to view this hinge with a Hager 1277 5 Knuckle, Plain Bearing, Tapped Leaves, Aluminum Entrance Hinge.
-
QuickShipNo
-
ManufacturerHager Companies
-
MPNHBB1277
- Product Design
-
Hinge CategorySlip In Hinge, Full Mortised Hinge
-
Base MaterialSteel
-
Usage LevelStandard Duty
-
ThrowStandard Throw
-
Bearing TypePlain Bearing
-
Knuckles5 Knuckle Hinge
-
Pin TypeStandard Hinge Pin
-
Hinge Tip TypeButton Tip
-
Hinge CornerSquare Corner
-
Hole PatternCommercial "C" Pattern
-
Number of Holes8 Holes
-
Swaging5/16" Swage
-
- Dimensions
-
Hinge Size4-1/2" x 4", 4-1/2" x 4-1/2"
-
Hinge Thickness.134" Thick
-
- Installation
-
Door TypeAluminum Doors
-
Installation ScrewsInstallation Screws Provided Accordingly:
4-1/2" x 4-1/2": All wood and all machine screws provided
4-1/2" x 4": All wood and all machine screws provided
Additional screw packs can be provided if listed in order comments before completing purchase.
-
- Finishes
-
FinishSatin Chrome (US26D)
-
- Compliance Details
-
Compliance DetailsBHMA Certified
-
ANSI DesignationA156.18, A8143
-
WarrantyLifetime Limited Warranty
-
Click to Print 4" Hinge Template
Click to Print 4-1/2" Hinge Template
4" Hinge Template. Select links above for additional templates.
