Hager BB1578, Ball Bearing Brass or Stainless Steel Slip-in Hinge for Aluminum Entrance, One Leaf Tapped

Hager BB1578, Ball Bearing Brass or Stainless Steel Slip-in Hinge for Aluminum Entrance, One Leaf Tapped
Hager Companies

Hager BB1578 Full Mortised Aluminum Entrance, ball bearing hinge with five knuckles and one leaf tapped. It comes in choice of Stainless Steel or Brass  with a non-rising removable stainless steel pin with button tip and plug. Hager BB1578 is a handed hinge. Available in two sizes.

PRICED PER PIECE - See full product details and specs in the tabs below.

See tabs below for additional information
    • SKU
      HGBB1578-4.5x4-US10B
    • Market price:$223.41
      • save 50%
    • Starting price: Price: $111.71 per item


    Aluminum Entrance hinges are for use on aluminum doors with aluminum frames. They are applied by inserting the hinge leaves through a slot in the door or frame.

    Available sizes:

    Hinge Size

    Gauge of

    Metal

    Hole Count

    Screw Size

    InchesmmMachineWood

      4-1/2" x 4"

      114 x 102

      0.134

      8

      1/2 x 12-24

      1-1/4 x 12

      4-1/2" x 4-1/2"

      114 x 114

      0.134

      8

      1/2 x 12-24

      1-1/4 x 12

    Hinge is provided with a non-rising removable pin with a button tip and plug.

    Available Finishes: See options above, See Hager Hinges Color Chart for a detailed list of Hager finishes.

    Custom finishes: Available through our office, for details and pricing please contact us or call us at 845-388-1300.

    Handing: Left handed and right handed.  Click on the link of How to Determine the Handing of a Door.

    Priced per piece.

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See Product Specs Tab for exact measurements.

    This product has a lifetime guarantee against defects in workmanship and materials.
     Click here to view our Full Warranty Policy.

    For Plain Bearing Aluminum Entrance Hinges, see our Hager 1578, Plain Bearing Brass or Stainless Steel Slip-in Hinge for Aluminum Entrance, One Leaf Tapped.

      • SKU
        HGBB1578-4.5x4-US10B
    • QuickShip
      No
    • Manufacturer
      Hager Companies
    • MPN
      HBB1578
    • Swing Direction
      Right Handed, Left Handed
    • Product Design
      • Hinge Category
        Slip In Hinge, Full Mortised Hinge
      • Base Material
        Brass, Stainless Steel
      • Usage Level
        Standard Duty
      • Throw
        Standard Throw
      • Bearing Type
        Ball Bearing
      • Knuckles
        2 Knuckle Hinge
      • Pin Type
        Standard Hinge Pin
      • Hinge Tip Type
        Button Tip
      • Hinge Corner
        Square Corner
      • Hole Pattern
        Commercial "C" Pattern
      • Number of Holes
        8 Holes
      • Swaging
        3/16" Swage
    • Dimensions
      • Hinge Size
        4-1/2" x 4", 4-1/2" x 4-1/2"
      • Hinge Thickness
        .134" Thick
    • Installation
      • Door Type
        Aluminum Doors
      • Installation Screws
        Installation Screws Provided Accordingly:
        4-1/2" x 4-1/2": All wood and all machine screws provided
        4-1/2" x 4": All wood and all machine screws provided
        Additional screw packs can be provided if listed in order comments before completing purchase.
    • Finishes
      • Finish
        Oil Rubbed Bronze (US10B), Satin Chrome (US26D), Satin Stainless Steel (US32D)
    • Compliance Details
      • Compliance Details
        BHMA Certified
      • ANSI Designation
        A2152, A5142, A156.18
      • Warranty
        Lifetime Limited Warranty

    Click to Print 4" Hinge Template

    Click to Print 4-1/2" Hinge Template

    4" Hinge Template. For additional templates see above.

    Hager BB1578 Aluminum Entrance Hinge

    Hinge complies with ANSI A2152 and ANSI A5142.
