Hawa Junior 80/B Sliding Door Hardware, up to 176 Lbs., Mortised, Top Hung System

Smooth, quiet operation
Rattle-Free bottom
Minimum installation height
Low headroom applications
Height adjustable
Suspension with carrier profile
Option of short and long bolt
Use in conjuction with Pre-Drilled Upper Track (not included in set)

Note: Order 2 sets for 2 bi-parting sliding doors.

See full products details and specs in tabs below

PRICED PER SET

See tabs below for additional information

Quantity

Add to compare

Track: Upper Track not included. Pre-drilled Upper Track sold separately.

Maximum Door Weight: 176 Lbs. (80 kg)

Minimum Door Thickness: 1-3/16" (30mm)

Application: For 1-leaf sliding doors. Can also be used for pocket door applications

Mounting: Hardware mortised to door

Headroom: For low headroom applications, gap between the door and upper track can be as small as 1/32" (1mm).

Installation:

Suspension with recessed support profile and installation-friendly suspension carriage with integrated metal cover cap
Suspension of running gears from below using hanger bolt
Wall mounting and ceiling installation. Additional hardware required for wall mount. (can be puchased through our office)

Adjustable Options:

Height adjustable: +/- 9/32" (7 mm)
Coarse adjustment +/- 1/8" (3 mm)
Fine adjustment +/- 5/32" (4 mm)
Track stopper with adjustable retention spring

Features:

Door Stop with adjustable retention spring
Low profile / minimum headroom
Quiet running action
Low wear and tear

Accessories: Additional Accessories can be purchased through our office.

Guide rail
Cover cap for upper track
Soft and Self closing mechanism

Priced Per Set

Please note, detailed images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product specs tab for exact measurements.

This product has a 1 year guarantee against defects in material and workmanship.
Click to view our Full Warranty Policy.

Click to view our Hawa Junior 120/B Sliding Door Hardware, up to 264 Lbs., Mortised, Top Hung System.

- SKU
  HF940.80.004
QuickShip
No
Manufacturer
Hafele
MPN
940.80.004, 940.80.118
Bolt Length
Standard M10 Bolt, Extended M10 Hanger Bolt
Dimensions
- Door Panel Weight
  175 Lb Doors

Click to Print

Click to Print Installation Instructions
