McKinney MK100 Concealed Hinge, Certified Grade 1, Doors up to 282 LB
The MK100 concealed hinge is ANSI/BHMA Grade 1 Certified and has greater hinge capacity than the MK4001A and MK80 Series. It's used on wood or hollow metal doors with a 1-3/8" minimum thickness, are non-handed, and include snap-on covers.
PRICED PER HINGE
See tabs below for additional information
Refined and minimal, the McKinney MK100 Concealed Hinges feature 3-Dimension adjustability for easy installation and door alteration.The snap-on covers conceal screws for a clean aesthetic.
Hinge Capacity:
Features
- For wood or hollow metal doors that are a minimum of 1-3/8" thick
- Covers included
- Base Materials: Hinge body - zinc alloy, Hinge arms - aluminum, Hinge covers - ABS plastic
- 180° opening angle
- UL Listed / ANSI/BHMA Grade 1 Certified
- 3-dimensional adjustability
- Available Finishes - Select from above. Custom finishes are available via a quote, please contact our office for information.
Benefits:
- Greater hinge capacity than the MK4001A and MK80 Series
- 20-minute fire rating
- Virtually disappears from view when door is closed
- Provides aesthetic continuity when door is open
- Refined and minimal
- Snap-on covers conceal screws for a clean aesthetic
- Easy installation and door alteration
Dimensions:
- 6-1/4" x 1-1/16"
- Gauge: 160.00
- No. of Holes: 8
- Fasteners: Metal: M5 x 20 screws, Wood: 35mm PHWS
PRICED PER HINGE
Also available in an electrified option, see our McKinney MK100 Electrified Concealed Hinge.
