NGP 9125 Meeting Stile, .875" Aluminum Casing with .375" Premium Grade Silicone Seal

NGP 9125 Meeting Stile, .875" Aluminum Casing with .375" Premium Grade Silicone Seal
National Guard Products

NGP 9125 meeting stile is designed to be surface mounted to the face of doors to seal a gap between a pair of double active doors. Comes with .875" Aluminum casing and .375" Premium Grade Silicone Seal. The premium grade seal is specially formulated to withstand greater temperature extremes while providing maximum protection against air infiltration. Available in various anodized finishes and length is custom cut to size.

PRICED PER FOOT - See full product details and specs in the tabs below.

See tabs below for additional information
    • SKU
      NG9125A
    • Market price:$29.35
      • save 15%
    • Starting price: Price: $24.95 per foot


    NGP 9125 meeting stile is designed to be surface mounted to the face of doors to seal a gap between a pair of double active doors. The premium grade seal is specially formulated to withstand greater temperature extremes while providing maximum protection against air infiltration.

    Recommended for areas using FM200 or Halon Fire Suppression Systems

    Seals: Contains a .375" Tan Silicone Plus Seal. It has very good abrasion resistance, tensile strength and memory.

    Please note:

    • Fire-rated Astragal Seals cannot replace any astragal required on the door by the door manufacturer to maintain its fire label
    • IBC, NFPA 80, NFPA105, and NFPA 252 require the gap at the meeting edge between fire labeled doors must not exceed 1/8"

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product specs for exact measurements.

    This product has a 3 year guarantee against defects in material and workmanship.
     Click here to view our Full Warranty Policy.

    For additional Meeting Stiles see our NGP 9115 Meeting Stile, .675" Aluminum Casing with .375" Premium Grade Silicone Seal

      • SKU
        NG9125A
    • QuickShip
      No
    • Manufacturer
      National Guard Products
    • MPN
      9125
    • Set
      Not Required, Required
    • About This Product
      • Retainer Material
        Aluminum
      • Seal Type
        Silicone
      • Door Type
        Double Active Doors
      • Mounting
        Surface Mounted
      • Temperature Range
        -100°F thru 500°F
    • Dimensions
      • Seal Height
        3/8"
      • Total Height
        1-1/4"
    • Installation
      • Installation Screws
        #6 x 3/4" stainless steel SMS provided
    • Finishes
      • Finish
        Clear Anodized Aluminum (US28), Dark Bronze Anodized Aluminum (313), Bronze Finish
    • Compliance Details
      • Compliance Details
        Fire Rated, Air Infiltration Rated, Smoke Rated, BHMA Certified
      • ANSI Designation
        R5E736
      • Warranty
        3 Year Limited Warranty
