Norton 9500, Door Closer, Surface Closer

Norton 9500, Door Closer, Surface Closer, Regular, parallel or top jamb to 3" reveal, No Hold Open, Aluminum Painted Finish
Norton

The 9500 Series Cast Iron door closer is perfect for high-traffic areas because it provides the strength, flexibility, and longevity your facility needs. This ANSI/BHMA Grade 1 closer is suitable for both exterior and interior doors. Its strong cast iron body and sleek, contemporary cover make it suitable for usage in a range of institutional settings that need to comply with ADA regulations. It is available in multiple finishes with a full range of arms, choose from the drop down menus. See more details in the description below.

PRICED PER UNIT

See tabs below for additional information
    • SKU
      NR-9500-689
    • Market price:$953.72
      • save 25%
    • Starting price: Price: $715.29 per item


    The 9500 Series Cast Iron door closer is perfect for high-traffic areas because it provides the strength, flexibility, and longevity your facility needs. This ANSI/BHMA Grade 1 closer is suitable for both exterior and interior doors. Its strong cast iron body and sleek, contemporary cover make it suitable for usage in a range of institutional settings that need to comply with ADA regulations.

    Features:

    • Exceeds 25 million cycles
    • Closer mounting plate included for easy installation
    • Adjustable spring sizes 1-6
    • Non-handed
    • Interior or exterior doors
    • Molded ABS plastic cover
    • All standard arm applications allow doors to swing 180°, conditions permitting
    • Staked valves
    • **CloserPlus® Arm
      • Door closers shall have a field reversible door stop. Hold open tension shall be adjustable effective at one point selected at installation, from 85° - 110° in five-degree increments. Closers shall be provided for parallel arm installation using a forged rigid steel main arm and secondary arm.
    • **Unitrol® Arm
      • Door closers shall have a fixed door stop feature effective at one point selected at installation, from 85° - 110° in five-degree increments. Door stop shall be cushioned by a shock-absorbing heavy-duty spring action effective at the [soffit plate] [arm shoe] pivot. [Closers shall be provided for parallel arm installation using rigid steel main arm and secondary arm lengths proportional to the door width.] [Closers shall be provided for top jamb installation using steel, rigid main arm and telescoping secondary arm adequate for the frame reveal of the openings.]

    Benefits :

    • Constructed with robust materials and internal components
    • Protects the door and frame from damage and reduces maintenance costs
    • Stringent testing supports a long-life of reliability
    • One package covers regular, top jamb, and parallel arm mounting
    • Low-profile projection provides clean aesthetic
    • Arm configurations meet broad range of applications
    • Staking limits ability to accidentally back out the valve while adjusting closer

    Certifications:

    • ANSI/BHMA A156.4, Grade 1
    • ANSI/BHMA A117.1
    • Americans with Disabilities Act (ADA) Compliant
    • Environmental Product Declaration (EPD)
    • UL 10C Positive Pressure up to 3 hours
    • UL-cUL Listed

    PRICED PER UNIT

    This product has a 30-year limited warranty against defects in material and workmanship. Click to view our Full Warranty Policy.

    Click here to view Norton 160, Door Closer, Surface Closer

      • SKU
        NR-9500-689
    • QuickShip
      No
    • Manufacturer
      Norton
    • MPN
      9500
    • Options
      Standard, Delayed Action, Metal cover
    • Drop Plates
      No Drop Plate, Narrow top rail drop plate, regular arm or pull side track, Narrow top rail drop plated, top jamb applications, Narrow top rail drop plate, parallel arm or push side track
    • Description
      • Series
        Norton 9500 Series
      • BHMA Grade
        Grade 1
      • Arm Type
        Regular, parallel or top jamb to 3" reveal, Parallel rigid arm (specify handing on note), Parallel rigid offset arm (specify handing on note), CloserPlus® Arm, Regular Rigid Arm, Unitrol® parallel arm (specify door width on note), Pull side slide track, Push side slide track
      • Handing
        Non Handed
      • Closer Body Material
        Cast Iron
    • Door Description
      • Door Opening Degree
        up to 180° Degree
    • Features
      • Function
        No Hold Open, Hold Open
      • Adjustable Spring
        Yes
    • Finishes
      • Finish
        Aluminum Painted (689), Dark Bronze Painted (690), Dull Bronze Painted (691), Black Painted (693), Medium Bronze Painted (694), Gold Painted (696), Dark Satin Bronze, Equiv (613e), Black Suede Powder Coat (BSP), White Suede Powder (WSP)
    • Compliance Details
      • Compliance Details
        ADA Compliant, UL 10C Positive Pressure up to 3 hours, Ul-cUL Listed, Environmental Product Declaration (EPD)
      • ANSI Designation
        ANSI/BHMA A156.4, Grade 1, ANSI/BHMA A117.1
      • Warranty
        30 Year Limited Warranty
