Rixson Q51 Series, Door Closer, 3/4" Offset, Quick Install

Rixson Q51 Series, Door Closer, 3/4" Offset, Quick Install, 36" Door Width, Model Q, Non-hold Open w/ Backcheck, Bright Brass Finish
Rixson

For optimal mechanical support and control of a door, the Rixson Q51 Series, Floor Door Closer is one of the best options. For enduring performance and dependability, it is made to comply with the laws of physics. The floor and bottom arm support the door's weight. This works perfectly for 3/4" door installation for interior doors weighing up to 250lbs.

PRICED PER UNIT

See tabs below for additional information
    • SKU
      RX-Q5103NBC-605
    • Market price:$3,901.89
      • save 25%
    • Starting price: Price: $2,926.42 per item
    Additional discounts will be applied when added to cart!


    For optimal mechanical support and control of a door, the Rixson Q51 Series, Floor Door Closer is one of the best options. For enduring performance and dependability, it is made to comply with the laws of physics. The floor and bottom arm support the door's weight. This works perfectly for 3/4" door installation for interior doors weighing up to 250lbs.

    Features:

    • Single acting, handed
    • Interior doors
    • 180 top pivot included
    • One M19 intermediate pivot included (closer cannot be ordered without the intermediate pivot)
    • Specify spring size 3, 4, or 5 when ordering
    • Doors will swing 5° beyond hold open point
    • Mortise arm with thru bolt attachment
    • Separate independent valves for closing speed, latch speed, and backcheck
    • Vertical door adjustment
    • Interchangeable spindle adapters
    • Door width up to 4' 0" (1219mm)

    Benefits:

    • Aesthetically appealing way to support and control the door
    • Constructed with robust materials and internal components
    • Concealment in-floor provides vandal resistance
    • Multiple valves provide enhanced control
    • Ideal for upper levels of multi-story buildings due to shallow depth design
    • Weight of door is supported by floor closer
    • Surface attached bottom arm allows closer removal without demounting door
    • Increased depth of cement case for easy closer removal

    Optional Features:

    • Delayed action option –  (non-hold open closers only) Closer will not have backcheck
    • Extended spindles available in 1/2" increments up to 2" longer than standard (please state on the note)
    • Automatic Hold Open specify 90°, 105° , (Option not applicable for Non-hold open)

    Certification:

    • Certain models UL Listed
    • Fire rated for 20 minute labeled doors

    PRICED PER UNIT

    This product has a 2-year limited warranty against defects in material and workmanship. Click to view our Full Warranty Policy.

    Click here to view Rixson 51 Series, Shallow Depth Floor Door Closers

      • SKU
        RX-Q5103NBC-605
    • QuickShip
      No
    • Manufacturer
      Rixson
    • Door Width
      36" (914mm), 42" (1067mm), 48" (1219mm)
    • Model
      Q - closers have a floor plate, QT - For threshold applications, no floor plate
    • Description
      • Series
        Norton 50 Series
      • Handing
        Right Handed, Left Handed
    • Door Description
      • Door Weight
        Up to 250 LB
      • Door Opening Degree
        N/A, 90°, 105°
    • Features
      • Function
        Non-hold Open w/ Backcheck, Automatic Hold Open w/ Backcheck, Fire Rated, Non-hold Open w/ Backcheck
    • Finishes
      • Finish
        Bright Brass (605), Satin Brass (606), Polished Bronze (611), Satin Bronze (612), Oil Rubbed Bronze (613), Dark Satin Bronze, Equiv (613e), Polished Nickel (618), Satin Nickel Plated (619), Flat Black (622), Bright Chrome Plated (625), Satin Chrome Plated (626), Black Suede Powder Coat (BSP), White Suede Powder Coat (WSP)
    • Compliance Details
      • Warranty
        2 Year Limited Warranty
