Topaz Topaz LED PCTS Flat Panel, 2' x 4', 20/30/40W, 3500K - 5000K CCT Selectable

Topaz LED PCTS FLAT PANEL, 2' x 4', 20/30/40W, 3500K - 5000K CCT Selectable
Topaz

This PCTS Flat Panel from Topaz provide color temperature and power selectability. Three popular wattages (30W, 40W, and 50W) and three CCT settings (3500K, 4000K, and 5000K) are available. For each of the nine available setups, choose the wattage and color temperature at installation.

PRICED PER UNIT

See tabs below for additional information
    • SKU
      TPPL24-40WPCTS-D
    • Starting price: Price: $70.23 per item


    This PCTS Flat Panel from Topaz provide color temperature and power selectability. Three popular wattages (30W, 40W, and 50W) and three CCT settings (3500K, 4000K, and 5000K) are available. For each of the nine available setups, choose the wattage and color temperature at installation. These panels are perfect for new construction or retrofit projects in offices, schools, healthcare facilities, institutions, and commercial applications due to their low profile and lightweight design.

    Key Features:

    • Choose wattage and color temperature at installation for 9 possible configurations
    • Up to 25% lighter than traditional fixtures
    • Low profile and light weight design
    • Backlit technology with precision optics for uniform illumination
    • Steel housing with white powder coat finish, smooth frame and polystyrene lens
    • Includes 18 AWG leads and 22 AWG dimming wires
    • Fits standard drop ceiling
    • ETL sanitation listing

    Electrical:

    • INPUT VOLTAGE: 120-277V
    • FREQUENCY: 50/60Hz
    • POWER FACTOR, THD %: >0.9, <20%
    • DIMMABLE: 0-10V, DOWN TO 1%

    Ratings:

    • ETL Sanitation listed
    • RoHS Compliant
    • IC Compliant
    • DLC Premium Listed

    Suggested Applications:

    • New construction or remodel
    • Office, schools
    • Healthcare facilities
    • Institutions and commercial applications

    PRICED PER UNIT

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail.

    This product has a 5 year-limited guarantee against defects in workmanship and materials.

    Click here to view our Full Warranty Policy.

      • SKU
        TPPL24-40WPCTS-D
    • QuickShip
      No
    • Manufacturer
      Topaz
    • MPN
      PL24-40WPCTS-D
    • General Specification
      • Input Voltage
        120-277V
      • Power Factor / THD%
        THD %: >0.9,
      • Lumens Per Watt
        Up to 140 LPW
      • Dimmable
        0-10V, DOWN TO 10%
      • CRI
        80
      • Functional Life (L70)
        50,000 Hours
      • Location Rating
        Damp
      • Ambient Operating Temperature
        -4°F to 113°F
    • Item Specification
      • Lighting Type
        LED Flat Panel
      • Lumens
        3,900, 4,550,5,200 (Selectable)
      • Watts
        30W, 35W, 40W (Selectable)
      • Fluorescent Replacement Wattage
        30W - 2x 32W T8 NBF (at 30W), 71W - 3x 32W T8 HBF (at 35W), 100W - 4x 32W T8 HBF (at 40W)
      • CCT - Color Temperature
        3500K/4000K/5000K Selectable
      • Beam Angle
        120°
      • Input Amps
        0.33/0.12A, 0.39/0.14A, 0.44/0.159A
    • Ratings
      • IC Rated
        Yes
    • Finishes
      • Finish
        White
    • Compliance Details
      • Compliance Details
        DLC Listed, ETL Sanitation listed, RoHS Compliant
      • Warranty
        5 Year Limited Warranty
