Pemko #ADJ2325V Adjustable Vinyl Divider and Threshold, Tile to Tile
Adjustable Width Threshold / Surface Divider Combo is great for applications where the width of the transition beneath the door may need to change without completely dismantling and replacing the threshold. Available with a single or double center piece. Designed to transition tile to tile. Made of high quality black vinyl and width is easily resized, see below.
36" LENGTH
Adjustable Width Threshold / Floor Surface Divider Combo is designed for applications where the width of the transition beneath a door may need to change without completely disassembling and reinstalling the threshold. This all vinyl product serves as a transition strip between the tile and concrete that join under a door.
Key Features of this Surface Divider / Threshold include:
The threshold is made up of 2 vinyl end pieces and either 1 or 2 vinyl centerpieces (select from options above). The centerpiece can be adjusted for various width applications. Full application with one centerpiece has a maximum total width of 9.5", while a double centerpiece has a maximum total width of 15.5", see product specs. The centerpiece has a height clearance of approx. .5".
The product is made of a slightly softer material which aids in the cutting and the fitting of the threshold. It also makes it easier to slide the tiles into the cavities on the tile side of the threshold.
Made of heavy duty, fire rated vinyl which will last through much usage. Dimensions comply with ADA Regulations.
This threshold also serves as a great surface for Door Bottom Sweeps or Automatic Door Bottoms to rest upon for a solid, proper seal.
- Fire Rated and ADA Compliant
- Adjustable width
- Convenient design - can be adjusted without completely disassembling threshold
- Available with one or two centerpiece application
- Separates floor surfaces under doors for greater sealing properties and safety
- Applied with construction glue (not included)
Installation guide included.
Installation Notes: Center section can be easily cut to the desired size with a utility razor. The threshold can be applied with glue to concrete or plywood using readily available construction adhesives such as Liquid Nails® (not included).
Note: Adhesives should be suitable with vinyl. Adhesives underneath the threshold may add as much as 1/32" - 1/13" of height and should be considered when calculating clearance.
This product has a 5 year guarantee against defects in material and workmanship.
Click here to view our Full Warranty Policy.
For a carpet to carpet version, see our Adjustable Vinyl Divider and Threshold, Carpet to Carpet
-
QuickShipNo
-
ManufacturerPemko Manufacturing
-
MPNADJ2325V8, ADJ2325V14
-
Center PieceSingle Center Piece, Double Center Piece
- Dimensions
-
Overall Height.5" Height
-
Overall Width9.5" Width, 15.5" Width
-
Threshold Length36" Length
-
Required Door Clearance.625" Height
-
- Product Design
-
Flat Saddle DesignSmooth Top Design
-
Threshold TypeCarpet Divider / Seam Binding
-
MaterialVinyl
-
- Finishes
-
FinishBlack
-
- Compliance Details
-
Compliance DetailsADA Compliant, Fire Rated, UL Classified
-
Warranty5 Year Limited Warranty
-
