PC Henderson 8/HY/75 Husky Glass Clamp Kit and Track, Sliding Glass Doors 8-10mm Thick

Glass Clamp for Sliding Glass Doors
PC Henderson

Glass Clamp Kit and Aluminum Track is for lightweight glass doors weighing up to 165 lbs each. Glass Doors may be 8mm or 10mm thick, up to 4'1" wide, and up to 7'10" tall (glass is not included).

PRICED PER SET - See full product details and specs in the tabs below.

See tabs below for additional information
    • SKU
      PH8/HY/75-280C72
    • Market price:$670.45
      • save 15%
    • Starting price: Price: $569.88 per set


    Key Product Features:

    • For lightweight glass applications such as office doors and small glass partitions.
    • Max. door height 7' 10" (2400mm)
    • Use with tempered or laminated glass (not included)

    Included Parts: See product specs and detailed images for visual aid.

    Configurations:

    • Overhead Mount
    • Single Glass Door Panel
    • Bypass Glass Door Panels with bypass track 2802A instead of Single Track 280A (bypass track not included)

    Materials: Aluminum track, white nylon hangers, wheels, and clip stops.

    Dimensions and Installation Information: Track is available in 6 and 8 ft. lengths. To order a 10 ft., 12 ft., or 16 ft. track, please contact us or call our office at 845-388-1300. For more information see product specs and Installation Instructions in tabs to the right.

    Door Bottom Guide: Kit includes bottom guide for 8 mm or 10mm glass thicknesses (indicate glass thickness in drop-down box above).

    Additional Customization Options: See product specs, customization tab and detailed images for more on these products.

    Please note, detailed images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product specs for exact measurements.

    This product has a 5 year guarantee against defects in material and workmanship.
     Click to view our Full Warranty Policy.

    See our Door Seals for Glass Doors category for weather and soundproofing products for Glass Doors.

      • SKU
        PH8/HY/75-280C72
    • QuickShip
      No
    • Manufacturer
      PC Henderson
    • MPN
      8/HY/75HUSKY_280A, 10/HY/75HUSKY_280A
    • Glass Thickness
      8mm (5/16 in.), 10mm (3/8 in.)
    • About This Product
      • Door Material
        Glass Doors
      • Mounting Type
        Overhead Mount
      • Door Mount
        Mortised
      • Track Type
        Box Track
      • System Type
        Single Sliding
      • Included Parts
        Aluminum Track 280A
        Glass Clamp Kit:
        Hangers (2 each)
        Glass clamps w/anti-lift stop (2 each)
        In-Track Stops (2 each)
        Glass guide (1 ea.)
      • Material
        Aluminum
    • Dimensions
      • Door Panel Weight
        165 Lb Doors
      • Door Width
        49" maximum (1250mm)
      • Track Length
        72" Length, 96" Length
    • Compliance Details
      • Warranty
        5 Year Limited Warranty

    Click to Print Product Specs

    Glass Clamp Kit:



    280A Aluminum Track (included)       F234C-144 Fascia for Overhead Track (optional)



    Included Parts:



    Click to Print Installation Guide.

     P.C. Henderson 8/HY/75 Installation

    Fascias: F234C-144 clear anodized aluminum facia that conceals the hanger and glass clamp for a neater, classier look.  To order any of these options, please contact us or call us at (845) 388-1300.

    Finishes Comply with the Following ANSI / BHMA Codes:

    • Aluminum Mill Finish - US27 / 719
