Adams Rite Deadlock MS1850S Series MS®, For Narrow Stile Aluminum Doors - QUICKSHIP
This model is a deadlock that provides maximum security for narrow stile aluminum doors. The lock comes with a choice of a straight or hook bolt, making it the perfect solution for both swinging and sliding doors. The product includes the lock body only; cylinder and/or thumbturn need to be purchased separately. Available in many options, choose from the dropdowns below.
See full product details and specs in the tabs below.
For more options and finishes, see our Adams Rite Deadlock MS1850S Series MS®, For Narrow Stile Aluminum Doors
PRICED PER PIECE
This deadlock provides maximum security for narrow stile aluminum doors.
Please note, strike plate, cylinder and/or thumbturn are not included with this product and are available for purchase separately.
For more options and finishes, see our Adams Rite Deadlock MS1850S Series MS®, For Narrow Stile Aluminum Doors
Cylinder Backset: Distance from the edge of the lock to the center of the cylinder hole
- 1-1/8" (28.6 mm) backset
Length of case (A) = 1-25/32" (45.2 mm)
Bolt: Eight-ply laminated stainless steel. Center ply has alumina-ceramic core to defeat any hacksaw attack, including rod-type “super” hacksaws. The over-center maximum security (MS) locking action assures that forced entry attempts to pry the door in any direction, up, down, or sideways will be defeated.
- Short Bolt (1850S-X2X) - same features as the MS1850S straight bolt, with a shorter throw. Please note, due to the special configuration of the bolt, the 1850S-X2X short throw deadlock is not available in the 7/8” backset or the radius with weatherstrip faceplate.
Installation: For details on how to install this deadlock, see our Installation Instructions.
Operation: 360° turn of the key or thumbturn projects or retracts the counterbalanced bolt. Key can be removed only when the bolt is in a positively locked or unlocked position. Lock accepts any standard 1" (25.4 mm) length, 1-5/32" (29.4 mm) diameter mortise cylinder with MS® cam, available separately. Lock accepts cylinder from either or both sides.
Additional Options: Schoolhouse option is available, please contact us for details and pricing. The lock has the same faceplate and backset options as standard function but is modified so that operation from the inside is "unlock only." The lock is handed and must be specified LH or RH.
Compatible Cylinders:
- Adams Rite #4036 - Mortise Cylinder
- Adams Rite #4066 - Thumbturn Insert
Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See Product Specs for exact measurements.
This product has a 10 year warranty against defects in materials and workmanship.
Click here to view our Full Warranty Policy.
Click here to view our Adams Rite Deadlock MS1847, Adjustable Bolt, For Narrow Stile Sliding Doors.
-
QuickShipYes
-
ManufacturerAdams Rite
-
MPNMS1850S; MS1851S; MS1851SW; MS1852S; MS1853S
- Product Details
-
Included PartsDeadlock, Faceplate, Mounting Screws
-
Case MaterialSteel with corrosion resistant plating
-
Faceplate TypeFlat Faceplate
-
Bolt TypeStraight Bolt
-
Bolt MaterialEight-ply laminated stainless steel, center ply has alumina-ceramic core
-
ANSI / BHMA GradeGrade 1
-
- Dimensions
-
Case Dimensions1" W x 6" H
Length varies with cylinder backset -
Faceplate Dimensions1" W x 6-7/8" H
-
Bolt DimensionsStraight Bolt: 5/8" x 1-3/8" x 2-7/8"
Hook Bolt: 5/8"x 1-3/8"
Short Bolt: 5/8"x 1-3/8" x 2-3/8" -
Bolt ThrowStraight Bolt: 1-3/8" Throw
Hook Bolt: 13/16" Throw
Short Bolt: 1-3/8" Throw -
Cylinder Backset1-1/8" Backset
-
- Installation
-
Door TypeNarrow Door, Swinging Door, Sliding Door
-
Door MaterialAluminum
-
HandingNon Handed
-
- Special Features
-
Maximum SecurityYes
-
- Finishes
-
FinishDark Bronze Anodized Aluminum (313), Clear Anodized Aluminum (US28)
-
- Compliance Details
-
Compliance DetailsBHMA Certified
-
Warranty10 Year Limited Warranty
-
