Adams Rite P8800 - P8700 Series, Pullman Narrow Stile Rim Exit Device

Adams Rite 8800 Series Exit Device for aluminum doors
Adams Rite

The Adams Rite P8800 - P8700 Series is an interlocking rim exit device for narrow stile aluminum doors. It features a 3/4" stainless steel Pullman latch bolt and is designed for applications that require a life-safety exit device. The dropdowns below provide several options.

See full product details in the tabs below.

PRICED PER PIECE

See tabs below for additional information
    • SKU
      ARP8801
    • Market price:$568.00
      • save 40%
    • Starting price: Price: $340.80 per item


    The Adams Rite P8800 - P8700 Series is an interlocking rim exit device for narrow stile aluminum doors. It features a 3/4" stainless steel Pullman latch bolt and is designed for applications that require a life-safety exit device. The dropdowns below provide several options.

    Click here to print the Adams Rite Exit Device Catalog.

    The product is an exit only device, no entry from outside. Additional trims can be added separately.

    Features:

    • Materials:
      • Active pushbar and back bar made of extruded aluminum, available in choice of finishes.
    • Handing
      • Non-Handed
    • Stile Width:
      • Minimum 2" stile. Fits ultranarrow, narrow, medium and wide stile aluminum doors.
    • Projection:
      • 2-1/2" when fully projected
      • 1-3/4" when dogged.
    • Dogging:
      • Standard dogging with 3/16” hex key.
    • Fasteners
      • Device mounted using standard type ‘F’ self-tapping screws. Rivnuts are provided for the P8700 only.
    • Strike:
      • Horizontally adjustable strike assembly body made of Zamak 5 with hardened steel roller. Standard strike assembly suitable for centering doors in 4" jamb. Strike plate adjusts 1/4" horizontally.

    Certifications:

    •  UL 305 Panic Hardware
    • ANSI/BHMA A156.3, Grade 1

    Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail.

    This product has a 10-year limited warranty against defects in materials and workmanship.
    Click here to view our Full Warranty Policy.

    Click here to view our Adams Rite Exit Device 8700 / 3700 Series, Starwheel Interlocking Rim, For Hollow Metal and Wood Doors.

      • SKU
        ARP8801
    • QuickShip
      No
    • Manufacturer
      Adams Rite
    • MPN
      P8800; P8700
    • Model
      P8800 Narrow stile rim exit device, P8700 Rim exit device for wood and hollow metal
    • Product Details
      • Included Parts
        Machine Screws
      • Exit Device Type
        Rim with Pullman
      • Model
        Life-safety
      • Series
        Adams Rite P8800 / 8700
      • Material
        Extruded Aluminum
    • Door Compatibility
      • Door Type
        Narrow Door
      • Door Material
        Wood, Hollow Metal
      • Door Width
        30" Opening Width, 36" Opening Width, 42" Opening Width, 48" Opening Width
      • Door Thickness
        Compatible with all door thicknesses
      • Stile Width
        2" minimum width
    • Dimensions
      • Projection
        2-1/2" Projection
      • Projection when Dogged
        1-3/4" Projection
    • Installation
      • Handing
        Non Handed
    • Finishes
      • Finish
        Dark Bronze Anodized (313), Black Anodized (335), Satin Aluminum, Clear Anodized (628), Satin Brass (US4), Stainless Steel, Satin (US32D), Bright brass (us3), Stainless Steel; Bright (US32)
    • Compliance Details
      • Compliance Details
        UL 305 Panic Hardware, ANSI/BHMA A156.3, Grade 1
      • Warranty
        10 Year Limited Warranty

    This exit device comes in a choice of additional options, please contact us for details and pricing.

    Please note that the alarm option cannot be combined with any other device or monitoring option.

    Device Options:

    • Motorized Latch Retraction (MLR) - Incorporates a powerful and efficient motor to unlatch the exit device while providing a quieter operation than the solenoid option. For more details, see our MLR Device Option Installation.
    • Cylinder Dogging ( non-fire rated devices only )  - a cylinder installed where a key must be inserted. As the key is turned, the cam on the cylinder turns and engages the dogging mechanism to hold the latchbolt retracted.

    Please note, the MLR Device option is supported by a 1 year electro mechanical warranty. When powered by an Adams Rite PS-SE power supply the 1 year warranty is upgraded to 5 years.

    Monitoring Options:

    • Single Switch
    • Dual Switch

    Mounted in the exit device pushbar on the hinge end, the switch can be used to activate a signal light, horn, monitor or other devices. For more details, see our Monitoring Option Installation.

    Please note, 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the MLR device option.
