HAWA Junior 100 B Acoustic Sliding Door Hardware Set with Soft Stop, up to 220 LB

The Hawa 100 B Acoustic Sliding Door Hardware, for Pocket Doors or Wall Mounting, effectively dampens noise, drafts, odors and unwanted light between two rooms. For 1 sliding wood door, for soundproof and thermally broken sliding door systems.

Click here to view the Hawa Acoustic Pocket Door Catalog or the Hawa Acoustic Wall Mount Sliding Door Catalog.

 Additional Required Components:

• Seal Set: Hafele Soundproof seal set for Sliding Door, HAWA Junior 100 B
• Pocket Doors: Upper Track for Hawa Junior 100 Series
• Wall Mounted Sliding Doors: Wall Mounted Track for Hawa Junior 100 Series

Specifications:

• Pocket Door or Wall Mount Application
• Low Opening Forces: <30 N (6.7 lbs.)
• Door weight: max. 100 kg (220 lbs.)
• Door width: 800–1300 mm (32 5/16"–56 5/16")
• Clear opening width: 750–1250 mm (29 1/2"–49 3/16")
• Door thickness- POCKET DOOR: 44–50 mm (1 3/4"–1 31/32")
• Door thickness-  WALL MOUNTED: 44–55 mm (1 3/4"–2 3/16")
• Height adjustable: ±2 mm (3/32")
• Sound rating: Depending on the door and wall construction a maximum sound insulation value of 41 decibels can be achieved. See catalog (linked above) for additional information.

Acoustic Pocket Door Hardware Kit Contents:

• 2 running gears
• 2 carrier profiles with suspension plate including M10 bolt
• 1 SoftStop, with retaining spring and ramp
• 1 SoftStop, with retaining spring
• 1 Cover cap set, plastic, aluminum finish
• 1 adjustment wrench

For an option with a door, see our Eclisse Soundproof Pocket Door Including Door Panel.
