Rixson F53 and F5310 Series, Door Closer, Independently Hung

Rixon F53 And F5310 Series, Door Closer, Independently Hung, 36" Door Width, Non-hold Open w/ Backcheck, Mounted Parallel to Frame, Bright Brass Finish
Rixson

For optimal mechanical support and control of a door, the Rixson F53 and F5310 Series, Floor Door Closer is one of the best options. For enduring performance and dependability, it is made to comply with the laws of physics. The floor and bottom arm support the door's weight. This works perfectly for standard door frame installation for interior doors weighing up to 250lbs.

PRICED PER UNIT

See tabs below for additional information
    • SKU
      RX-F5303NBC-605
    • Market price:$3,054.39
      • save 25%
    • Starting price: Price: $2,290.79 per item
    Additional discounts will be applied when added to cart!


    For optimal mechanical support and control of a door, the Rixson F53 and F5310 Series, Floor Door Closer is one of the best options. For enduring performance and dependability, it is made to comply with the laws of physics. The floor and bottom arm support the door's weight. This works perfectly for standard door frame installation for interior doors weighing up to 250lbs.

    Features:

    • Single acting, handed
    • Interior doors
    • Used as a concealed floor closer for independently hung doors (butt hinges, pocket pivots, or continuous hinges)
    • Closer does not support the weight of door (hanging means must be specified when ordering)
    • Auxiliary stop recommended
    • Includes closer, mortised rail, and arm with slider
    • Maximum swing 90°
    • Separate independent valves for closing speed, latch speed, and backcheck
    • Interchangeable spindle adapters
    • Floor plate standard (for threshold applications a 1/2" extended spindle is required)
    • F5310: For use in 90° pocket door installations where closer is located in the pocket (can only be used with F519 pocket pivots)

    Benefits:

    • Aesthetically appealing way to support and control the door
    • Constructed with robust materials and internal components for long life and consistent operation.
    • Ideal for upper levels of multi-story buildings due to shallow depth design

    Optional Features:

    • Delayed action option –  (non-hold open closers only) Closer will not have backcheck
    • Extended spindles available in 1/2" increments up to 2" longer than standard (please state on the note)
    • Automatic Hold Open specify 90°, 105° , (Option not applicable for Non-hold open)

    Certification:

    • Buy American Act

    PRICED PER UNIT

    This product has a 2-year limited warranty against defects in material and workmanship. Click to view our Full Warranty Policy.

    Click here to view Rixson HM51 Series, Door Closer, Hollow Metal Door And Frame Prep

      • SKU
        RX-F5303NBC-605
    • QuickShip
      No
    • Manufacturer
      Rixson
    • Door Width
      36" (914mm), 42" (1067mm), 48" (1219mm)
    • Description
      • Series
        Norton F53, F5310 Series
      • Handing
        Right Handed, Left Handed
    • Door Description
      • Door Weight
        Up to 250 LB
      • Door Opening Degree
        105°
    • Features
      • Function
        Non-hold Open w/ Backcheck, Mounted Parallel to Frame, Automatic Hold Open w/ Backcheck, Mounted Perpendicular to Frame
    • Finishes
      • Finish
        Bright Brass (605), Satin Brass (606), Polished Bronze (611), Satin Bronze (612), Oil Rubbed Bronze (613), Dark Satin Bronze, Equiv (613e), Polished Nickel (618), Satin Nickel Plated (619), Flat Black (622), Bright Chrome Plated (625), Satin Chrome Plated (626), Black Suede Powder Coat (BSP), White Suede Powder Coat (WSP)
    • Compliance Details
      • Warranty
        2 Year Limited Warranty
