Rockwood RM790 Architectural Flush Cup Pull - up to 38" OA
Rockwood Architectural Flush Cup Pull. Available up to 38" Overall Length. This Pull can be purchased as a single pull or as a push / pull set with back to back mounting. This flush pull can be used with swinging and sliding doors. Many variations of size, material and finishes are available, see below for details and options.
NOTE: Center to Center of Mounting holes will be 2" less than overall length.
PRICED PER PIECE / SET
Rockwood Flush Cup Pull for High End Commercial Applications.
Dimensions:
- Overall Length: Custom lengths from 5" - 38" Overall Length
- CTC Length: 2" less than overall length
- Cup Depth: 5/8"
- Door Thickness: Select from options above
Mounting Types:
- Single Pull -Â provided with thru-bolt mount
- Push / Pull Set -Â provided with back to back concealed mounting
Additional Fastener Options (can be purchased through our office):
- Concealed mounting single pulls, Standard and Heavy Duty Types 6, 6R, 8 - See  Additional Options
- Prepped for Pull - RM790 one side, screws visible, mating door pull other side. Door pull CTC must be less than 2" of overall flush pull height. Ex: RM790 is 16" OA, mating door pull CTC is 14". Contact our office for a quote.
Priced per set / piece
Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product specs for exact measurements.
This product has a 1 year guarantee against defects in material and workmanship.
 The mounting is guaranteed for the lifetime of the building. Click here to view our Full Warranty Policy.
For our Rockwood Upholstery Leather Straight Pull with Round Ends see our Rockwood RM6180Â Door Pull.
-
QuickShipNo
-
ManufacturerRockwood Company
-
MPNRM790
-
Door TypeWooden Door, Metal Door
-
Product TypeSingle Pull - Thru-Bolt Mount, Push / Pull Set - BTB Mounting
- About this Product
-
Base MaterialStainless Steel
-
- Installation
-
Door Thickness1.75" Thick Door, 2" Thick Door, Other (Add to Order Comments)
-
- Finishes
-
FinishOil Rubbed Bronze, Equiv. (10BE), Polished Stainless Steel (US32), Satin Stainless Steel (US32D), Black Suede Powder Coat, White Suede Powder Coat, Black Powder Coat, Red Powder Coat, White Powder Coat
-
 Standard Mountings - Select from Options Above |
||
Also available in Heavy Duty Back to Back Mounting:Â features hex drive for positive tightening and large overall size for superior strength. Recommended for high frequency and rough service openings. Â |
||
 Optional Mounting Types - Can be purchased through our office |
||
Also available in Heavy Duty Concealed Mounting: features two set screws 180º apart. To view more details on these mounting types, see Mounting Types for Door Pulls. |
