Securitron DK-12 Stand Alone Keypad with Illuminated keys

Securitron DK-12 Stand Alone Keypad with Illuminated keys
Securitron

For lower security applications like traffic control, the DK-12 Stand Alone Keypad is perfect. The one-piece DK-12, which supports 99 user codes, including Passage mode and Lockout mode, is simple to install and program. Though designed primarily for indoor use, external spaces not directly exposed to rain or snow can be reliably used with the optional rain cover (WCC) and gasketed backbox (WBB).

PRICED PER UNIT

See tabs below for additional information
    • SKU
      SCDK12
    • Market price:$233.00
      • save 40%
    • Starting price: Price: $139.80 per item


    For lower security applications like traffic control, the DK-12 Stand Alone Keypad is perfect. The one-piece DK-12, which supports 99 user codes, including Passage mode and Lockout mode, is simple to install and program. Though designed primarily for indoor use, external spaces not directly exposed to rain or snow can be reliably used with the optional rain cover (WCC) and gasketed backbox (WBB).

    Features:

    • Single gang, stainless steel plate with low voltage mounting ring
    • 12-key illuminated 3x4 keypad
    • True 10-digit operation (10 digits plus * and # keys)
    • 99 user code capability
    • Easy programming from the keypad
    • Passage mode and Lockout mode
    • Configurable audible keystroke echo
    • Red, green and yellow LEDs for status and programming feedback
    • Fail secure or fail safe-capable
    • Easy to install with simple hand tools
    • 5A SPDT timed, control relay output
    • Request to exit (REX) input
    • Primarily for indoor applications

    Specifications:

    • Operating Temperature:  -10˚ to 140˚ F [-23˚ to 60˚ C]
    • Electrical Consumption:
      • 100 mA at 12 or 24 VDC
      • 325 mA at 12 or 24 VAC
      • Max 30 Volt input
      • 5A SPDT Relay

    Optional Accessory:

    • Rain Cover (WCC)
    • Gasketed Backbox (WBB)
