Securitron DM62 Double Durable Magnalocks, Electronic Lock
For interior, perimeter, and external access control, the Securitron DM62 Double Durable Magnalocks is a reliable and simple-to-maintain solution. The Securitron DM62 is incredibly durable and will continue to function long after most structures wear out. Applications for hollow metal, concrete-filled metal, wood, glass with aluminum frames, and Herculite doors are supported by flexible mounting choices.
PRICED PER UNIT
For interior, perimeter, and external access control, the Securitron DM62 Double Durable Magnalocks is a reliable and simple-to-maintain solution. The Securitron DM62 is incredibly durable and will continue to function long after most structures wear out. Applications for hollow metal, concrete-filled metal, wood, glass with aluminum frames, and Herculite doors are supported by flexible mounting choices.
Features:
- Ultra-secure collapsing blind nuts mount to door frame for strength and reliability
- Fully sealed for weather-resistant operations
- 3' [1 m] of jacketed, stranded conductor cable for each lock
- Automatic dual-voltage —no field adjustment required
- Instant release circuit —no residual magnetism
- Noise suppression with built-in MOV
- Efficient, low-power usage
- Rust resistant — all ferrous metal surfaces plated for durability
Optional Feature:
- Monitoring Options
- BondSTAT Monitor (B)
- Door Position Switch (D)
- BondSTAT Monitor & Door Position Switch (BD)
- Strike Plate Options
- Offset Strike (OS)
Optional Accessory:
- ASCWB-DM62CL (Alum 1-1/2” Spacer — Concrete/Wood Bracket, DM62, Clear)
Specifications:
- Holding Force: 1,200 lbs [544kg]
- Operating Temperature: -40˚ to 140˚F [-40˚ to 60˚C], Indoor or Outdoor use
- Electrical:
- 250 mA at 12 VDC
- 150 mA at 24 VDC
Certifications:
- UL 10C Listed
- CAN4-S104, CAN/ ULC-S533 Listed
- ANSI/BHMA A156.23, Grade 2; E08511-1000 Compliant
- CSFM- California State Fire Marshal Approved
PRICED PER UNIT
This product has a lifetime limited warranty against defects in material and workmanship. Click to view our Full Warranty Policy.
Click here to view our Securitron M62 Durable Magnalocks, Electronic Lock
-
QuickShipNo
-
ManufacturerSecuritron
-
Monitoring OptionsNo Monitoring, BondSTAT Monitor, Door Position Switch, BondSTAT Monitor & Door Position Switch
-
Strike Plate OptionsStandard Strike, Offset Strike
- About this Product
-
Collection / SeriesMagnalock
-
Lock TypeMagnetic Lock
-
- Specifications
-
GradeGrade 2
-
- Finishes
-
FinishSatin Stainless Steel (630)
-
- Compliance Details
-
Compliance DetailsUL 10C Listed, CAN4-S104, CAN/ ULC-S533 Listed, CSFM- California State Fire Marshal Approved
-
ANSI DesignationANSI/BHMA A156.23, Grade 2; E08511-1000 Compliant
-
WarrantyLifetime Limited Warranty
-
