Securitron MK Mortise Keyswitch

Securitron MK Mortise Keyswitch, MK Model
Securitron

Convert a common mortise cylinder into a fully functional keyswitch. The MK keyswitch comes standard with a 12/24 VDC bi-color LED and supports electric lock control, alarm panel arming, reset, and override when paired with any 1-1/4" (32 mm) or 1-1/8" (28 mm) mortise cylinder (not included). It is a 5 A rated plunger switch. Cylinder sold separately.

PRICED PER UNIT

See tabs below for additional information
    • SKU
      SCMK
    • Market price:$163.00
      • save 35%
    • Starting price: Price: $105.95 per item


    Convert a common mortise cylinder into a fully functional keyswitch. The MK keyswitch comes standard with a 12/24 VDC bi-color LED and supports electric lock control, alarm panel arming, reset, and override when paired with any 1-1/4" (32 mm) or 1-1/8" (28 mm) mortise cylinder (not included). It is a 5 A-rated plunger switch. Cylinder sold separately.

    Features:

    • 12 or 24 VDC
    • Bi-color LED
    • Backing bracket permits integration with any 1-1/4" [32mm] or 1-1/8" [28mm] mortise cylinder (not included)
    • Support for 1-1/2" cylinder using spacer ring and backset
    • Additional switch position on backing bracket allows another switch to be activated by turning the key in the opposite direction
    • 5A-rated plunger switch
    • Includes anti-tamper screws

    Optional Features:

    • Momentary or Alternate Switch
      • Momentary Switch - changes state during activation and reverts to its original state upon deactivation  (ex. Doorbell)
      • Alternate Switch - changes state upon activation and does not change back until reactivated (ex. light switch)
    • SPDT or DPDT relay
      • Single Pole – Double Throw
      • Double Pole – Double Throw
    • Narrow Stile, Single- or Double-Gang
    • Local annunciation via Piezo sounder Additional switch add on

    Models:

    • MK  -  Momentary, SPDT, Single Gang, Green/Red LED
    • MK2  - Momentary, DPDT, Single Gang, Green/Red LED
    • MKA  - Alternate, SPDT, Single Gang, Green/Red LED
    • MKA2  - Alternate, DPDT, Single Gang, Green/Red LED
    • MKAN  - Alternate, SPDT, Narrow, Green/Red LED
    • MKAN2  - Alternate, DPDT, Narrow, Green/Red LED
    • MKN  - Momentary, SPDT, Narrow, Green/Red LED
    • MKN2  - Momentary, DPDT, Narrow, Green/Red LED
    • MKPZ  - Momentary, SPDT, Double Gang, Green/Red LED, Audible
    • MKAPZ  - Alternate, SPDT, Double Gang, Green/Red LED, Audible

    Accessories:

    PRICED PER UNIT

    This product has a lifetime limited warranty against defects in material and workmanship. Click to view our Full Warranty Policy.

    Click here to view our Securitron PB5 Medium Round, Push Button

      • SKU
        SCMK
    • QuickShip
      No
    • Manufacturer
      Securitron
    • Model
      Momentary, SPDT, Single Gang (MK), Momentary, DPDT, Single Gang (MK2), Alternate, SPDT, Single Gang (MKA), Alternate, DPDT, Single Gang (MKA2), Alternate, SPDT, Narrow (MKAN), Alternate, DPDT, Narrow (MKAN2), Momentary, SPDT, Narrow (MKN), Momentary, DPDT, Narrow (MKN2), Momentary, SPDT, Double Gang, Audible (MKPZ), Alternate, SPDT, Double Gang, Audible (MKAPZ)
    • Finishes
      • Finish
        Satin Chrome (US26D)
    • Compliance Details
      • Warranty
        Lifetime Limited Warranty
