TruSil 100 Silicone Sealant

TruSil 100 Silicone Sealant is a high performance acetoxy curing silicone sealant adhesive that demonstrates high strength adhesion and excellent weatherability under the most severe conditions.  We recommend using TruSil 100 to apply the installation channels onto our signature Flood Barrier Shield and to caulk around exterior door hardware, such as Doorway Thresholds.

PRICED PER TUBE (10.0 FL OZ PER TUBE)

See tabs below for additional information
    • SKU
      TH-TruSil 100
    • Starting price: Price: $11.75 per item


    TruSil 100 Silicone Sealant is a high performance acetoxy curing silicone sealant adhesive that demonstrates high strength adhesion and excellent weatherability under the most severe conditions.

    Product Features:

    TruSil has been specially formulated to meet low VOC requirements and is recognized for its smooth consistency, low temperature application, ease of tooling, and quick cure time. Upon cure, TruSil100 is a medium modulus, permanently elastomeric material that meets ASTM-C920 performance standards and can withstand +/- 25% joint movement. TruSil 100 can be used for extended periods at temperatures up to 400°F (232°C).

    Door Hardware Applications:

    We recommend using TruSil 100 to apply the installation channels onto our signature Flood Barrier Shield and to caulk around exterior door hardware, such as Doorway Thresholds.

    Additional Applications:

    TruSil 100 is an NSF 51 Certified Silicone Sealant, making it the ideal caulk to use in and around food processing and storage. Applications include repair of kitchen and restaurant appliances, sinks, stainless steel walls, walk-in-coolers, ice machines, & various types of refrigeration units, produce and meat storage/display, and repair of piping, seals, gaskets, and valves that may come into contact with food.

    • Exterior windows, skylight doors, and siding
    • Kitchen, Bath, & Restaurant tile, sinks, tubs, and counters
    • HVAC/R, Plumbing, Electrical, Roofing
    • RV, trailer and specialty vehicle manufacture and repair
    • Industrial Seals
    • Walk in coolers, ice machines, and other types of refrigeration units
    • Piping, seals, gaskets, and valves where contact with food may occur

    Compliance:

    See Product Data tab for Standards and Compliance Details.

      • SKU
        TH-TruSil 100
    • Series
      TMH Flood Barrier
    • QuickShip
      Yes
    • Manufacturer
      Trademark Hardware
    • MPN
      TruSil100

    Click to Print TruSil 100 Silicone Sealant Installation Guide

    General Installation Guide

    1. Thoroughly clean and dry desired area.
    2. Cut tip off cartridge. Screw nozzle on end and cut tip to desired bead size. Insert cartridge into standard caulk gun.
    3. Hold at 45° angle and apply by pushing sealant ahead of nozzle to achieve a smooth seal. Apply using a steady, even pressure to completely bridge joints.
    4. Complete tooling within 5 minutes. Use dry paper towel to remove excess material. Smooth caulk using wet finger or a damp cloth for a clean, neat appearance.
    5. Sealant normally “skins over” in 5 minutes, dries to touch in 1 hour, and cures & bonds in 24 hours. Allow 7 day cure time to reach maximum strength.

    Installation Guide onto Flood Barrier Channels

    1. Insert TruSil Sealant into compatible caulking gun and prep as above. (Figure 1)
    2. Apply 2 beads of sealant running along the back of the Floor Barrier Channel. (Figure 2)
    3. Screw Flood Barrier Channel onto wall / door frame. (Figure 3)
    4. Apply a bead of sealant running along each side of the applied Flood Barrier Channel. (Figure 4).

    TruSil 100 Silicone Sealant being inserted into Caulking Gun for Application TruSil 100 Silicone Sealant being applied to back of Flood Barrier Channel for Enhanced Installation Flood Barrier Channel Being Screwed into Door Frame with TruSil 100 Silicone Sealant Backing TruSil 100 Silicone Sealant being applied to the sides of a Flood Barrier Channel for enhanced instalaltion
