Securitron AQD Series Distribution Boards, Fire Trigger / Relay Interface Board

Securitron AQD Series Distribution Boards, Fire Trigger / Relay Interface Board
Securitron

When a fire system alarm situation occurs, the PDB-1R uses an end-of-line resistor to activate a form "C" contact. The unit switches the output from "Normally On" to "Normally Off" in response to the trigger. Other triggered reactions include input triggers that latch until they are reset, ground fault triggers, and status feedback to fire control or notification systems.

PRICED PER UNIT

See tabs below for additional information
    • SKU
      SCPDB1R
    • Market price:$55.00
      • save 35%
    • Starting price: Price: $35.75 per item


    When a fire system alarm situation occurs, the PDB-1R uses an end-of-line resistor to activate a form "C" contact. The unit switches the output from "Normally On" to "Normally Off" in response to the trigger. Other triggered reactions include input triggers that latch until they are reset, ground fault triggers, and status feedback to fire control or notification systems.

    Features:

    • 115 or 230 VAC input
    • All combinations of AQ power supplies and distribution boards are UL listed
    • Dual voltage 12 or 24 VDC field selectable continuous output
    • Up to 82% efficiency which results in decreased operating costs and lengthens the lifespan of electronics
    • Tolerates brownout or overvoltage input ± 15% of nominal voltage
    • Thermal shutdown protection with auto restart
    • Circuit breaker protects against overcurrent and reverse battery faults
    • Integrated battery charging circuit prevents overvoltage on locking devices
    • Available with a single relay fire trigger or individually triggered relayed outputs

    Specifications:

    • Operating Temperature: 32˚ to 110˚ F [0˚ to 43˚ C]  , Indoor use
    • Electrical:
      • Supports up to two (2) sealed gel, AGM or wet lead acid batteries
      • Up to 93% efficiency
      • Low noise design with ripple as low as 70mV p-p
      • Outputs are Class 2 limited when used with PTC polyswitch distribution boards
      • Dual voltage 12 or 24 VDC field selectable continuous output
      • Single voltage 12 or 24 VDC continuous output

    Certification:

    • UL294 Listed
    • UL603 Listed
    • ULC-S318 Listed
    • ULC-S533 Listed
    • RoHS Compliant
    • REACH Compliant

    PRICED PER UNIT

    This product has a lifetime limited warranty against defects in material and workmanship. Click to view our Full Warranty Policy.

    Click here to view our Securitron AQD6 Series Switching Power Supply

      • SKU
        SCPDB1R
    • QuickShip
      No
    • Manufacturer
      Securitron
    • Fuse Rating
      2 Amp
    • Compliance Details
      • Compliance Details
        UL294 Listed, UL603 Listed, ULC-S318 Listed, ULC-S533 Listed, RoHS Compliant, REACH Compliant, CE Compliant
      • Warranty
        Lifetime Limited Warranty
