Securitron AQL104 Series Intelligent Power System

Securitron AQL104 Series Intelligent Power System, 10 Amp at 24 VDC, Single Voltage Power Supply Only
Securitron

The Securitron AQL104 Series Intelligent Power System of single voltage switching power supply, which is UL approved, has a dedicated quick battery charging circuit and can support up to 16 outputs with 10 Amps at 24 VDC. Available with optional (B100) multi-voltage factory or field setup and (NL4) network monitoring and control.

PRICED PER UNIT

See tabs below for additional information
    • SKU
      SCAQL104
    • Market price:$439.00
      • save 40%
    • Starting price: Price: $263.40 per item


    The Securitron AQL104 Series Intelligent Power System of single voltage switching power supply, which is UL approved, has a dedicated quick battery charging circuit and can support up to 16 outputs with 10 Amps at 24 VDC. Available with optional (B100) multi-voltage factory or field setup and (NL4) network monitoring and control.

    Features:

    • Low battery cutoff protects batteries from deep discharge
    • Dedicated fast charger prolongs battery life
    • Enhanced surge immunity for input/output protection
    • LockSafe™ keeps locks cooler by providing a separate, dedicated battery charging circuit
    • OutSmart™ technology dual-color LED notification which prevents incorrect voltage application to locking devices [Green: 12 V | Blue: 24 V
    • Auxiliary output rated 1.4 A continuous
    • Mix and match UL Listing
    • Instant auto-switch to battery on AC loss
    • Multi-voltage with B100
    • Integrated Fire Alarm Interface (FAI) allows main output shutdown or disconnect on a per output basis when using an R8 output module
    • Network ready with optional Netlink™ module

    Specifications:

    • Operating Temperature: 32˚ to 120˚ F [0˚ to 49˚ C]
    • Electrical:
      • 12 VDC or 24 VDC output
      • 12 VDC & 24 VDC output (optional) with B100
      • 120 or 230 VAC input
      • Up to 91% efficiency

    Certification:

    • UL 294 Listed
    • UL 603 Listed
    • UL 1076 Listed
    • ULC-S318 Listed
    • ULC-S318 Listed
    • CSA C22.2 #107.1
    • RoHS Compliant

    PRICED PER UNIT

    This product has a lifetime limited warranty against defects in material and workmanship. Click to view our Full Warranty Policy.

    Click here to view our Securitron AQL102 Series Intelligent Power System

      • SKU
        SCAQL104
    • QuickShip
      No
    • Manufacturer
      Securitron
    • Model
      (AQL104) Single Voltage Power Supply Only, (AQL104-E1) Single Voltage Power Supply with E1 Enclosure
    • Compliance Details
      • Compliance Details
        UL 294 Listed, UL 603 Listed, UL 1076 Listed, ULC-S318 Listed, ULC-S319 Listed, CSA C22.2 #107.1, RoHS Compliant
      • Warranty
        Lifetime Limited Warranty
