Securitron EMB Electromechanical Bar

Securitron EMB Electromechanical Bar, 36", Clear Anodized Finish
Securitron

The Electromechanical Exit Bar (EMB) is intended to be used as an initiate device for a delayed egress timer or on magnetically locked, non-fire-rated doors. By pushing the bar, internal switches are triggered, releasing the lock. The EMB can be used in outdoor settings thanks to optional water-resistant switches. Meets "no special tools or knowledge" code requirements.

PRICED PER UNIT

See tabs below for additional information
    • SKU
      SCEMBCL36
    • Market price:$375.00
      • save 35%
    • Price: $243.75


    The Electromechanical Exit Bar (EMB) is intended to be used as an initiate device for a delayed egress timer or on magnetically locked, non-fire-rated doors. By pushing the bar, internal switches are triggered, releasing the lock. The EMB can be used in outdoor settings thanks to optional water-resistant switches. Meets "no special tools or knowledge" code requirements.

    Features:

    • Low profile design requires only 1/4" [6.35mm] movement for activation
    • Can be field cut to accommodate non-standard openings up to 48" [1219mm]
    • Uses same mounting pattern as the TSB and DSB
    • Direct retrofit for some competitor footprints
    • Mechanical action activates a DPDT relay
    • 5A rated output to allow free egress or initiate an exit delay timer
    • Redundant switches ensure reliable, fault-tolerant operation
    • All metal construction
    • 16 ft. [4.8m] 22 AWG 6 conductor cable and armored door cord included

    Optional Feature:

    • Weather-resistant upgrade

    Specifications:

    • Operating Temperature: -4˚ to 185˚ F [-20˚ to 85˚ C] , Indoor use
    • Electrical: Max current 1.5A at 30VDC

    Certification:

    • UL 294 Listed
    • CAN/ULC -S533

    PRICED PER UNIT

    This product has a lifetime limited warranty against defects in material and workmanship. Click to view our Full Warranty Policy.

    Click here to view our Securitron TSB Touch Sense Egress Bar

      • SKU
        SCEMBCL36
    • QuickShip
      No
    • Manufacturer
      Securitron
    • Length
      36", 42", 48"
    • Model
      Standard, Weather Resistant
    • Finishes
      • Finish
        Black Anodized (BK), Clear Anodized (CL)
    • Compliance Details
      • Compliance Details
        CAN/ULC-S533 Listed
      • ANSI Designation
        ANSI/UL 294 Listed
      • Warranty
        Lifetime Limited Warranty
