Pemko #3452 Door Bottom, 1.25" Aluminum Rain Drip Casing with Rubber Fin Seal

Pemko #3452 Door Bottom, 1.25" Aluminum Rain Drip Casing with Rubber Fin Seal
Aluminum Door Bottom Sweep with Rain Drip Cap and Vinyl Fin Seal Aluminum Door Bottom Sweep with Rain Drip Cap on Indoor Wooden Door Aluminum Door Bottom Sweep with Rain Drip Cap on Exterior Door Bright Dip Gold Anodized Door Bottom Sweep with Rain Drip Cap and PemkoPrene Seal Bright Dip Gold Anodized Door Bottom Sweep with Rain Drip Cap on Exterior Door Dark Bronze Anodized Door Bottom Sweep with Eco-V Vinyl Seal and Rain Drip Cap Dark Bronze Anodized Door Bottom Sweep with Rain Drip Cap on Indoor Wooden Door

This door bottom sweep is a great addition to seal exterior doors, or to protect the edges of interior doors. The high quality aluminum casing has a Rain Drip Cap which deflects water to prevents seepage through the gap under doors and protect the door from abuse. It is fitted with a Eco-V Vinyl or PemkoPrene Seal which reduces infiltration of fire, smoke drafts, moisture, air and dust. Available in many finishes and is custom cut to size.

PRICED PER FOOT.

Market price: $2.40
save 15%
Price: $2.04
Finish
Seal Type
Size (Inches)
Qty
Save to wishlist
SKU P3452AV
Options Eco-V (Vinyl) Insert, PemkoPrene Insert
Shipping See Shipping Tab Below
Description

This door bottom sweep is a great additional to seal exterior doors, or to protect the edges of interior doors. Made of high quality aluminum with a choice of rubber seals. Available in a variety of aluminum finishes and is custom cut to size.

Key Features Include:

Casing Design: This door bottom sweep is designed to be surface mounted to the face of an exterior or interior door. The casing extends approximately 1" along the height of the door. Casing is made of high quality aluminum that will withstand traffic abuse and continuously provide superior performance.

Seals: Casing is fitted with a choice of PemkoPrene or Eco-V Vinyl Fin Seal. Eco-V is comparable to standard vinyl, however it is a newer, greener and more environmentally friendly version. It surpasses the quality and durability of standard vinyl, resulting in a longer service life and less need for replacement. The seal extends .25" (1/4") past the rain drip cap, and can fill gaps up to .5" (1/2").

Both PemkoPrene and Eco-V Vinyl remain flexible in extreme temperatures to ensure quality performance through all weather conditions.

Rain Drip Cap: Casing has a Rain Drip Cap which projects .25" (1/4") from the casing to deflect water and prevent seepage. Additionally, it protects the bottom of the door from traffic abuse.

Compliance: Door Bottom is fire and smoke rated. Additionally, the Eco-V seal carries a UL Classified Listing and UL GreenGuard Gold Compliance. PemkoPrene Seal is BHMA Certified, see Product Data tab for more information.

  • High Quality Aluminum Casing
  • Rain Drip Cap Prevents Water Seepage and Protects Door
  • For Exterior or Interior Door
  • PemkoPrene or Eco-V Vinyl Fin Seal
  • Seals Gaps up to .5"
  • Custom Cut to Size

Installation Guide and screws provided. Screws are colored to coordinate with casing.

Inserts: Aluminum and Clear Anodized Finishes are supplied with gray insert. All other finishes are supplied with black inserts. For additional combinations, contact us or call us at 845-388-1300.

Please note, images are for illustrative purposes only. They are not actual photos. Therefore, actual colors may vary slightly and size may be enlarged to show detail. See product specs for exact measurements.

This product has a 5 year guarantee against defects in material and workmanship.
Click here to view our Full Warranty Policy.

This product is also available with a brush seal, see our Aluminum Rain Drip Door Sweep with .82" Nylon Brush Seal.

Product Specs
Compliance Details

Click to View Ratings Explained

Door Bottom Sweep with Eco-V Vinyl Seal:

Smoke Rating for Door Bottom with Eco-V Vinyl Seal by Pemko     Fire Rating for Door Bottom Sweep with Eco-V Vinyl Seal by Pemko     UL Classification Rating for Door Bottom Sweep with Eco-V Vinyl Seal by Pemko     GreenGuard Gold Compliance for Door Bottom Sweep with Eco-V Vinyl Seal and Rain Drip Cap by Pemko

Door Bottom Sweep with PemkoPrene Seal:

Smoke Rating for Door Bottom with PemkoPrene Seal by Pemko     Fire Rating for Door Bottom Sweep with PemkoPrene Seal by Pemko     BHMA Certification for Door Bottom Sweep with PemkoPrene Seal by Pemko

Finishes Comply with the Following ANSI / BHMA Codes:
  • Aluminum Mill Finish - US27 / 719
  • Clear Anodized Aluminum - US28 / 628
  • Dark Bronze Anodized Aluminum - US10B / 710
  • Bright Dip Gold Anodized Aluminum - US3 / 707
  • Gold Anodized Aluminum - US4 / 688
  • Satin Nickel Anodized Aluminum - US15 / 619
  • Painted White Aluminum - 714
Shipping / Returns
  • Ship Time:
    • This product is custom made to your specifications, please allow 10-14 Business Day to ship.
    • Ships via major carriers, such as UPS or FedEx Ground, with tracking information provided.

  • Domestic Shipping Fees- (Hawaii and Alaska not Included):
    • FREE SHIPPING on orders over $200.00 (excludes oversized and freight orders).
    • There will be a flat $19.99 shipping and handling fee on orders under $200.00.
    • Oversized Items: Items 86" and above have an oversize surcharge of $70.00
    • Freight Orders: Items 95" and above require freight shipment and have a shipping charge of $150.00
    • Orders totals above $1,500.00 will ship free, regardless of size.

  • Alaska and Hawaii, Canada, and International Shipping:
  • Returns:
    • This product is custom made and is not returnable.
    • We are commited to your satisfaction, as a courtesy, we may, at our discretion accept returns with a minimum 25% restock fee.
    • Weatherstripping products will not be considered for returns.
    • Item must be in new, resaleable condition.
    • Please call or email us to receive an RMA number before returning. No returns will be processed without an RMA number.
    • Return shipping is customer's responsibility. A return address will be provided with RMA#.
    • If you are shipping via USPS (not recommended) do NOT require signature as we will not be able to pick up your package from local post office facility.
