Rixson 5020 Series, Door Closer, Center Hung, Double Acting

Norton 5020 Series, Door Closer, Center Hung, Double Acting, 36" Door Width, Non-hold Open w/ Backcheck, Bright Brass Finish
Rixson

For optimal mechanical support and control of a door, the Rixson 50 Series, Floor Door Closer is one of the best options. For enduring performance and dependability, it is made to comply with the laws of physics. The floor and bottom arm support the door's weight. This works perfectly for standard door frame installation for interior doors weighing up to 250lbs.

PRICED PER UNIT

See tabs below for additional information
    • SKU
      RX-5023NBC-605
    • Market price:$3,064.56
      • save 25%
    • Starting price: Price: $2,298.42 per item
    Additional discounts will be applied when added to cart!


    For optimal mechanical support and control of a door, the Rixson 50 Series, Floor Door Closer is one of the best options. For enduring performance and dependability, it is made to comply with the laws of physics. The floor and bottom arm support the door's weight. This works perfectly for standard door frame installation for interior doors weighing up to 250lbs.

    Features:

    • Double acting, non-handed
    • Interior doors
    • 340 top pivot included
    • Separate and independent valves for closing speed, latch speed, and backcheck
    • Available with floor plate or threshold installation
    • Door may only swing 130° in either direction
    • Available with floor plate or threshold installation
    • Cycolac, rust-proof cement case
    • Interchangeable spindle adapters

    Benefits:

    • Ideal for upper levels of multi-story buildings due to shallow depth design
    • Aesthetically appealing way to support and control the door
    • Centering arm with adjusting screws in face of door (critical for double acting doors)
    • Concealment in-floor provides vandal resistance
    • Multiple valves provide enhanced control
    • Constructed with robust materials and internal components
    • Weight of door is supported by floor closer

    Optional Features:

    • Delayed action option –  (non-hold open closers only) Closer will not have backcheck
    • Extended spindles available in 1/2" increments up to 2" longer than standard (please state on the note)
    • Automatic Hold Open specify 90°, 105° , (Option not applicable for Non-hold open)
    • Arm reinforcement bracket for wood doors prefix
    • Frame stop required on lock edge; if not supplied by frame manufacturer, Norton Rixson 60131 is recommended

    PRICED PER UNIT

    This product has a 2-year limited warranty against defects in material and workmanship. Click to view our Full Warranty Policy.

    Click here to view Rixson 50 Series, Door Closer, Center Hung, Single Acting

      • SKU
        RX-5023NBC-605
    • QuickShip
      No
    • Manufacturer
      Rixson
    • Door Width
      36" (914mm), 42" (1067mm), 48" (1219mm)
    • Description
      • Series
        Norton 5020 Series
      • Handing
        Right Handed, Left Handed
    • Door Description
      • Door Weight
        Up to 250 LB
      • Door Opening Degree
        90°, 105°
    • Features
      • Function
        Non-hold Open w/ Backcheck, Automatic Hold Open w/ Backcheck
    • Finishes
      • Finish
        Bright Brass (605), Satin Brass (606), Polished Bronze (611), Satin Bronze (612), Oil Rubbed Bronze (613), Dark Satin Bronze, Equiv (613e), Polished Nickel (618), Satin Nickel Plated (619), Flat Black (622), Bright Chrome Plated (625), Satin Chrome Plated (626), Black Suede Powder Coat (BSP), White Suede Powder Coat (WSP)
    • Compliance Details
      • Warranty
        2 Year Limited Warranty
